MAXXDRIVE® XD Parallel Gear Units
Using robust and proven technology
The MAXXDRIVE® XD industrial gear unit is available as a three- and four-stage helical gear unit. The housing design succeeds follows the proven UNICASE housing principle and has been specially optimised for external loads. Due to the elongated arrangement of gear stages, the housing has a large centre distance, enabling a U-shaped drive design. Especially with lifting gear drives, the cable drum and the motor can thus easily be arranged on the same gear side same side of the gearbox. Furthermore, the housings are equipped with an inspection cover as standard.
Many options are adopted from our tried and tested modular industrial gear unit series, so that delivery times are similar to those for our standard MAXXDRIVE® industrial gear units. We offer short planning and delivery times. This is made possible due to the extensive knowledge of our experts about our experts' extensive knowledge of the specific requirements for every application, as well as optimised stocking of components.
UNICASE parallel gear motor
Slim and powerful
- Slim design for space-saving installation
- Robust grey cast iron housing
- High efficiency for low operating costs
- Various bearing concepts guarantee high axial and radial load capacities
- Quiet running
- Robust design for long life and easy maintenance
- Optional: Drywell version for mixers and agitators
- Cheap to run thanks to low maintenance
- Application-specific versions
.png)
IE5+ Ultra High-Efficiency Synchronous Motors
The new generation of NORD IE5+ synchronous motors are manufactured in-house and are especially well-suited for intralogistics. These motors feature a compact, hygienic design with smooth surfaces for high corrosion resistance and easy cleaning. A motor-integrated encoder comes standard and an integrated mechanical brake is optional. By using these motors, the number of system variants can be reduced, lowering operating and maintenance costs. They have high compatibility and are intended for use with NORD Variable Frequency Drives (wall or cabinet mounted versions only).
Highlights
- Performance: 0.5 - 5.5 HP
- Worldwide approvals and acceptance
- Flexible motor mounting: direct mounting, NEMA, IEC
Advantages
- Highest operational efficiency with IE5+ technology
- Reduction of variants through constant torque over a wide speed range
- Easy to clean and corrosion-resistant
- Fanless motor design
- Reduced TCO and fast ROI
- Non-ventilated variant (N-Design) for hygienic wash-down areas
- Ventilated variant (F-Design) with a high overload capacity
- Fully matched NORD modular system solution with gear unit, motor and variable frequency drive
- US availability
- 71 frame N design available now
- 90 frame N and F designs Q2 2022
- 71 frame F design Q3 2022
