Features:
- 7 sizes: SK 5217, SK 6217, SK 7217, SK 8217, SK 9217, SK 10217, SK 11217
- Type: M1/M3
- Nominal transmission ratios: 6.3 - 22.4
Execution:
- Robust roller bearings with long service life
- Effective variant of fan cooling
- Various possibilities of motor mounting
- Delivery of ready-to-install complete systems with coupling, brakes, monitoring etc. possible
- Attached, easily accessible backstops for simple change of direction of rotation
- Proven, one-piece block housing principle
Features:
- Optimum sealing enables long operating times without leakage
- Low noise emission due to high-precision bevel gears
- Effective fan cooling due to optimized fans and air flow routing
- High torque capacity
- Increased lubricant life minimizes maintenance costs
- And many more...
NORD MAXXDRIVE® Industrial Gear Units provide high output torques from 15,000 Nm to 282,000 Nm and are perfect for use in heavy duty applications such as agitators, conveyor belt drives, mixers, mills, drums or crushers.
Industrial gear units are available as helical gear units or bevel gear units. They are constructed with the UNICASE housing which was developed by us and can accommodate large roller bearings, which guarantee a long service life. By the way: NORD is the industrial gear unit manufacturer with the world's largest industrial gear units in a UNICASE housing.
- Powerful: NORD industrial gear units offer very high output torques up to 282,000 Nm.
- Long service life: Optimised geometries ensure excellent load capacity, long life and low noise.
- Robust: Our industrial gear units are equipped with high quality, low friction bearings and an especially torsionally rigid one-piece UNICASE housing.
- Flexible: The gear units can be combined with all of our electric motors.
Our optional SK TU4-PNS module provides additional safety. Safe inputs and outputs can be connected to the application via connectors. In addition, a rotary encoder can be connected to monitor the safe drive solution. In combination with a safety PLC, drive electronics offer reliable communication via PROFIsafe over PROFINET.
One can easily integrate functions such as Safely Limited Speed (SLS), Safe Direction (SDI) or Safe Operation Stop (SOS) and thus achieve SIL 3 (Safety Integrity Level 3) or PLe (Performance Level 3) Category 4.
Discover your savings potential
With the NORD ECO-Box, you get a detailed insight into the consumption of your system and uncover opportunities to reduce your energy requirements by analysing the results.Our advisory concept
Primarily, the NORD ECO service shows the savings potential of your application in order to optimise energy consumption for lower CO₂ emissions as well as cost savings. Our consulting concept is based on many years of experience in the production of electric motors and cooperation with customers from over 100 industries. This accumulated knowledge is continuously incorporated into the further development of our drives so that we can offer you suitable products for application optimisation.
